Basic Info.

Model NO.	GL-250
Bit Type	Diamond Bit
Drilling Way	Rotary
Drilling Depth (M)	250, 200, 150, 100, 80m
Drilling Rod Dia.(Mm)	50
Types	Core Drill Rig
Transport Package	Standard Exporting Packing.
Specification	Max. torque (Nm): 1700
Trademark	GLORYTEK
Origin	Beijing, China
HS Code	8430503900
Production Capacity	100sets/Month

Product Description

Small Core Drilling Rig, Portable Water Well Drilling MachineXY-1/XY-1A/GL200/GL250/GL300 small drill rig widely used in drilling family wells, drilling industry wells and drilling survey geological sampling, SPT service etc. Drilling dia. will from 50-200mm or larger according to clients requirement. Different layer condition will need different bits, soil or soft layer will need clay bit, or ally bit, drag bit, for hard rock will need diamond bit, tricone bit etc.Features: 1.with oil pressure automatic feed mechanism, it can improve drilling efficiency and reduce workers' physical work. 2.it adopts ball cassette clip to replace chuck and can perform non-stop rod reversing. It is easy to operate ,safe and reliable.3.a pressure gauge is equipped at the bottom of a hole to grasp the condition of the hole.4.the centralized handle is easy to operate and easy to maintain.5.compact structure: drilling rig, pump and diesel engine are on the same base. 6.light weight and easy decomposition to quick to move, so it is applicable to plains and mountainous areas.Technical Parameters:

Specifications			Models
			XY-1	XY-1A	GL200	GL250	GL300
Drill		Drilling depth	100m	100/180 m	250m	250m	300m
		Initial hole dia	110mm	150mm	200mm	200mm	200mm
		Final hole dia	75mm	75mm	75mm	75mm	75mm
		Drill rod dia	42mm	43mm	50mm	50mm	50mm
		Angle range	75°-90°	75°-90°	75°-90°	75°-90°	75°-90°
		Dimensions(L×W×H)	1640×1030×1440 (mm)	1620×970×1560(mm)	1700×1030×1270 (mm)	1700X1030X1270(mm)	1070×1030×1270 (mm)
		Weight(without power unit)	500kg	620kg	580kg	580kg	750kg
Swivel Head		Spindle stroke	450mm	450mm	450mm	450mm	450mm
		Spindle lifting capacity max	25KN	25KN	30KN	30 KN	max 45 KN
Hoist		Max .lifting capacity(single rope)	10KN	15KN	20/40/90/180	20KN	20KN
Power	diesel engine	Model	S1100A2	S1100A2	L28N	L28N	L28N
		Rated power	10.3KW	10.3KW	16.2KW	20KW	20KW
		Rated speed	2000r/min	2200r/min	2200r/min	2000r/min	2000r/min
	motor	Model	Y132M-4	Y160M‐4	Y160L-4	Y160L-4	Y160L-4
		Rated power	7.5kW	11KW	11KW	15KW	15KW
		Rated speed	1440r/min	1460r/min	1460r/min	1440r/min	1440r/min

These models can also be mounted with TRAILER CHASSIS or CRAWLER CHASSIS, just see pictures bellow:

Four-wheel Trailer Type Crawler Type
Mud Pump Specification:BW160/ BW160-10 /BW250 Mud Pump can be mounted on drill rigs as per different drilling requirement.

Specifications	Models
	BW160	BW160-10	BW250
Type	Horizontal single cylinder double acting reciprocating piston pump	Horizontal three cylinder reciprocating single acting piston pump	Horizontal three cylinder reciprocating single acting piston pump
Liner Dia. (mm)	95	70	80/65
Stroke (mm)	85	70	100
Weight (include power section) (Kg)	200	430	760
Dimension: L*W*H (mm)	1110*725*965	1450×745×970	1000×995×650
Theoretical flow (L/min)	160	160/107/67/44	250/145/90/52/166/96/60/35
Rated Pressure (MPa)	1.3	2.5/4/6.5/10	2.5/4.5/6/6/4/6/7/7
Strokes Per Minute	85	200/132/83/55	200/116/72/42/200/116/72/42
Input Power(kW)	5.5	11	15
